DC Motors |
|
|
|
| |
|
 Data Group: 220
SKU: 1111025
Weight (Kg): 0.1000
Decsription: PC-130SF-09400
HS Code: 8501.31.6000
Applications: Instrument, auto mirriors
 |
|
|
|
|
| |
Untitled Document
MFG Model |
VOLTAGE |
NO? LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
EFF |
CURRENT |
TORQUE |
V |
V |
RPM |
A |
RPM |
A |
mN.m |
|
W |
% |
A |
mN-m |
g-cm |
| PC-130SF-15160 |
3.0-9.0 |
4.8 |
7000 |
0.15 |
4960 |
0.42 |
16.6 |
1.63 |
0.85 |
42.6 |
1.21 |
65.3 |
6.4 |
| PC-130SF-10315 |
6.0-18.0 |
12 |
9000 |
0.08 |
6350 |
0.25 |
20 |
1.96 |
1.36 |
44.6 |
0.72 |
78.4 |
7.69 |
| PC-130SF-09400 |
6.0-24.0 |
12 |
7000 |
0.06 |
5130 |
0.15 |
14.43 |
1.4 |
0.75 |
42.5 |
0.45 |
57.7 |
5.66 |
| PC-130SF-09480 |
6.0-24.0 |
12 |
6000 |
0.05 |
4800 |
0.108 |
12.33 |
1.21 |
0.61 |
49.6 |
0.37 |
55 |
5.39 |
| PC-130F-18120 |
3.0-4.5 |
3 |
9500 |
0.16 |
6260 |
0.505 |
8.1 |
0.79 |
0.52 |
35.63 |
1.4 |
31 |
3.04 |
| PC-130F-12240 |
3.0-9.0 |
6 |
9500 |
0.1 |
6800 |
0.254 |
6.95 |
0.68 |
0.49 |
33.39 |
0.66 |
27.7 |
2.72 |
| PC-130F-10370 |
6.0-12 |
9 |
8900 |
0.1 |
6410 |
0.148 |
8.45 |
0.83 |
0.56 |
33..38 |
0.43 |
34.16 |
3.35 |
| PC-130S-09400 |
6.0-18.0 |
12 |
9300 |
0.07 |
7100 |
0.132 |
8.5 |
0.83 |
?0625 |
42.5 |
0.38 |
36 |
3.53 |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
