DC Motors |
|
|
|
| |
|
 Data Group: 1553
SKU: 1112013
Weight (Kg): 0.2000
Decsription: RF-300CH-11400
HS Code: 8483.40.9000
Applications: Meters
 |
|
|
|
|
| |
Untitled Document
Model |
Voltage |
No-Load |
At Maximum Efficiency |
Stall |
Operating Range |
Nominal DCV |
Speed |
Current |
Speed |
Current |
Torque |
Output Power |
Torque |
Current |
RPM |
A |
RPM |
A |
g.cm |
mN.m |
W |
g.cm |
mN.m |
A |
| RF-300CH-11400 |
1.0-6.3 |
3V |
3000 |
0.018 |
2400 |
0.65 |
4.3 |
0.42 |
0.11 |
21 |
2.06 |
0.29 |
| RF-300CH-11440 |
0.7-5.0 |
2V |
2200 |
0.015 |
1600 |
0.055 |
2.8 |
2.8 |
0.06 |
12 |
1.18 |
0.17 |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
