DC Motors |
|
|
|
| |
|
 Data Group: 197
SKU: 1112027
Weight (Kg): 0.1000
Decsription: FK-280RA-20125
HS Code: 8501.31.6000
Applications: Automotive Products> Retractable Rearview Mirror / Door Lock Actuator
Office Automation Equipment>
 |
|
|
|
|
| |
MFG Model |
VOLTAGE (V) |
NO? LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
Operating Range |
Normal |
Speed (RPM) |
Current (A) |
Speed (RPM) |
Current (A) |
Torque (g-cm) |
Power (W) |
Current (A) |
Torque (g-cm) |
FK-280RA-20125 |
3.0-9.0 |
6.0V |
10000 |
0.14 |
7560 |
0.57 |
21.08 |
1.64 |
2.48 |
117 |
PC-280-20125 |
3.0-9.0 |
6.0V |
10000 |
0.14 |
7560 |
0.57 |
21.08 |
1.64 |
2.48 |
117 |
PC-280-16210 |
3.0-12.0 |
6.0V |
6000 |
0.07 |
4260 |
0.28 |
18.03 |
0.79 |
0.98 |
81.91 |
PC-280-15265 |
6.0-12.0 |
12.0V |
10000 |
0.07 |
7230 |
0.3 |
24.96 |
1.85 |
1.15 |
119 |
PC-280-10420 |
6.0-24.0 |
12.0V |
6000 |
0.04 |
4270 |
0.13 |
14.49 |
0.64 |
0.4 |
62.25 |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
