Stepper Motors
Data Group: 802
SKU: 1122018
Weight (Kg): 1.0000
Decsription: 39BYG003
HS Code: 8501.10.4040
Applications: Office Automation, banking equipment, Automobil control unit, telecom, home appliance
Untitled Document
Mfg
Lead Wire
Step Angel
Motor Length
Rate Voltage
Rate Current
Phase Resistance
Phase Inductance
Holding Torque
Rotor Inertia
Detent Torque
Motor Weight
Model
Numbers
(Degree)
(mm)
(V)
(A)
( Ω )
(mH)
(g.cm)
(g. c㎡)
(g.cm)
(kg)
39BYG003
4
1.8
20
12
0.48
25
22
1000
11
50
0.12
39BYG013
4
1.8
20
6.5
0.4
6.8
6.5
550
11
50
0.12
39BYG215
4
1.8
34
12
0.4
30
42
2100
20
120
0.18
39BYG221
4
1.8
34
5
1
5
3
1800
20
120
0.18
39BYG408
4
1.8
38
13
0.5
26
30
1800
24
180
0.2
39BYG601
4
1.8
44
13.5
0.3
45
80
3100
40
250
0.25
39BYG104
6
1.8
26
6.3
0.42
15
8.5
800
13
70
0.14
39BYG301
6
1.8
31
4.5
0.5
9
3.5
1000
18
100
0.16
39BYG404
6
1.8
38
6
0.8
7.5
7
2000
24
180
0.2
