Stepper Motors |
|
|
|
|
|
 Data Group: 3649
SKU: 1040124
Weight (Kg): 1.0000
Decsription: 35BYG304
HS Code: 8483.40.9000
Applications:
 |
|
|
|
|
|
| Mfg Model |
Gear Ratio |
Length of Geared Box |
Holding Torque Geared |
Mass |
Step Angle |
Motor Length |
Lead Wires |
Rated |
Rated Current |
Phase Resistance |
Phase Inductance |
| Voltage |
| I |
L2 mm |
(Kg-cm) |
kg |
Degree |
L1 mm |
Number |
VDC |
A |
Ω |
mH |
| 35BYG304 |
N/A |
N/A |
1.25 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-5 |
5.2:1 |
31 |
4.5 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-14 |
13.6:1 |
39 |
12 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-19 |
19.2:1 |
39 |
16.8 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-27 |
26.8:1 |
39 |
23.5 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-51 |
51:1 |
47 |
44.6 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-71 |
71:1 |
47 |
62 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| 35BYG304-100 |
99.5:1 |
47 |
87 |
|
1.8 |
28 |
4 |
3.5 |
1 |
3.5±10% |
3.5±20% |
| Gear Ratio |
5.18 |
13.6 |
19.2 |
26.8 |
51 |
71 |
99.5 |
| Gear box length(mm) |
31 |
39 |
39 |
39 |
47 |
47 |
47 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
