DC Motors
Data Group: 832
SKU: 1162047
Weight (Kg): 0.1000
Decsription: K6PK12-2.6L
HS Code: 8483.40.9000
Applications: Cell phones
Untitled Document
MFG Rated Voltage Operating Voltage Starting Voltage Rated Speed Rated Current Stall Current Rotation Weight End
Model (VDC) (VDC) (VDC) (RPM) (mA) (mA) Direction (g) Play
6PK 12-2.0L 1.3 0.9-1.6 0.8 20000 60 260 C.W 1.3 0.10-0.3
6PK 12-2.2L 1.3 0.9-1.6 0.8 22000 60 300 C.W 1.3 0.10-0.3
6PK 12-3.0L 1.3 0.9-1.6 0.8 30000 80 460 C.W 1.3 0.10-0.3
