DC Motors
Data Group: 3177
SKU: 1112334
Weight (Kg): 0.5000
Decsription: RS-550VC-7527-13.2
HS Code: 8483.40.9000
Applications:
Untitled Document
MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
OPERATING
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
TORQUE
CURRENT
RANGE
V
r/min
A
r/min
A
mN-m
g-cm
W
mN-m
g-cm
A
KS-550-7527
6.0 - 14.4
12
18200
1.15
16130
8.97
47.8
488
80.7
421
4292
70
KS-550-7527-13.2
6.0 - 14.4
14.4
19800
1.3
17620
10.5
64.7
660
119
588
5994
85
KS-550-13514
6.0-15
12
15300
1.10
13514
7.035
44
449
60.6
440
4491
65
KS-550-6534
6.0-15
12
16000
1.00
14100
7.75
50
500
72.3
434
4400
60
KS-550-3550 9-30 12 4800 0.17 4240 1.3 25.6 261 11.4 221 2253 9.9
KS-550-3754 12-32 12 4100 0.2 3610 1.48 34.8 355 13.1 292 2977 10.9
CE and RoHS approved
