DC Motors
Data Group: 181
SKU: 1112377
Weight (Kg): 0.1000
Decsription: FF-N20PA-11155/18
HS Code: 8501.31.6000
Applications: Digital Camera, Camera, Car CD/MD Player / Digital Video Camera
Untitled Document
MFG Model
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
OPERATING
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
EFF
TORQUE
CURRENT
RANGE
VDC
r/min
A
r/min
A
mN·m
g·cm
W
%
mN·m
g·cm
A
FF-N20S-13115
1.2-3.0
2.4
15600
0.06
12200
0.55
0.28
2.8
0.55
44.2
1.4
15
FF-N20PA-10190
2.0-5.0
3
12100
0.045
9390
0.16
0.21
2.1
0.2
0.92
9.4
0.54
FF-N30S-09140
2.0-5.0
3
6353
0.03
6353
0.103
0.26
2.6
0.17
55
1.1
11
FF-N30S-10140
2.0-5.0
4.5
10175
0.05
10175
0.163
0.4
4
0.417
56.9
1.7
17
FF-N20S-06310
3.0-6.0
5
6680
0.02
6680
0.07
0.2
2
0.137
39.1
0.6
6.25
FF-N20PN-8260
1.5 - 6.0
5
14600
0.043
11150
0.14
0.26
2.6
0.3
1.08
11
0.45
FF-N20PA-11155
1.5 - 6.0
5
19400
0.048
1.10
