DC Motors |
|
|
|
|
|
 Data Group: 2043
SKU: 1112387
Weight (Kg): 0.1000
Decsription: FC-130S-2480-DS
HS Code: 8483.40.9000
Applications: Model planes
 |
|
|
|
|
|
无标题文档
| Description |
Speed |
Current |
Torque |
Efficiency |
Power |
| R.P.M. |
Amps |
Grcm |
Eff (%) |
W(output) |
W (input) |
| Locked Rotor |
0 |
7.696 |
218.788 |
0 |
0.000 |
90.400 |
| Max-Torque |
0 |
7.696 |
218.788 |
0 |
0.000 |
90.400 |
| Max-Efficiency |
24213 |
2.835 |
52.410 |
39 |
13.032 |
33.687 |
| Max-W(out) |
15403 |
4.498 |
109.104 |
33 |
17.258 |
52.827 |
| MFG Model: |
FC-130S-2480PW-R/45 |
| Rated Voltage: |
12.0 V |
| Rated Power Output: |
13.03 W |
| Started Torque |
218 g-cm |
| Ambient Temperature |
20 Degree C |
| No-Load R.P.M |
36000 RPM |
| No-Load Current |
0.45 A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
