DC Motors |
|
|
|
|
|
 Data Group: 269
SKU: 1112190
Weight (Kg):
Decsription: RS-755-5027F
HS Code: 8501.31.6000
Applications: Electrical Tools
 |
|
|
|
|
|
Untitled Document
| MFG Model |
VOLTAGE |
|
NO LOAD |
|
AT MAXIMUM EFFICIENCY |
STALL |
| OPERATING |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
EFF |
CURRENT |
TORQUE |
| VDC |
VDC |
RPM |
A |
RPM |
A |
mN.m |
g.cm |
W |
% |
A |
g.cm |
mN.m |
| RS-755-5027F |
6.0-12 |
12 |
10000 |
1.4 |
8400 |
4.87 |
45.7 |
466 |
40.56 |
71 |
29.6 |
3258 |
319.41 |
| RS-755-3262 |
12.0-24 |
12 |
8900 |
0.45 |
7400 |
2.11 |
43.3 |
442 |
33.93 |
70 |
12.22 |
3079 |
301.86 |
| RS-755-8512F |
6.0-9.6 |
9.6 |
16700 |
2.8 |
14006 |
19.81 |
98.2 |
1002 |
144.12 |
76 |
112.61 |
6480 |
635.29 |
| RS-755-19175 |
12.0-38 |
36 |
4800 |
0.18 |
3900 |
0.61 |
33.6 |
343 |
13.83 |
64 |
2.71 |
1870 |
183.33 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
